Basic Info.
Model NO.
DR-120-24
Input Voltage
100-240VAC
Connection Mode
Series Switching Power Supply
Starting Mode
Separate-excited Switching Power Supply
Voltage Regulating Mode
Width Modulation Type
Power Supplying System
Terminal Power Distribution Equipment
Energy Transmission
One-way Transmission
Modulation System
PWM
Certification
CE, RoHS, ISO, CCC, Bis
Brand
Nvvv
Output Current
5A
Product Name
DIN Rail Switching Power Supply
Efficiency
88%
Quality
100%Factory
Output Voltage
24V
Application
CCTV Camera,LEDs,3D Printer,Machines
Output Frequency
50/60Hz
Transport Package
Safety Packing
Specification
65.5*125.5*10mm
Trademark
NVVV
Origin
China
Product Description
| DR-120 120W Din Rail Power Supply | ||||
| Project | Technical index | |||
| Output | DC voltage | 12V | 24V | |
| Rated current | 10A | 5A | ||
| Rated power | 120W | 120W | ||
| Ripple and noise | <120mV | <150mV | ||
| Voltage accuracy | ±2% | ±1% | ||
| Ripple and noise | ±10% | |||
| Load adjustment rate | ±1% | |||
| Linear adjustment rate | ±0.5% | |||
| Input | Voltage range / frequency | 85-264VAC 47Hz~63Hz (120VDC~370VDC) | ||
| Efficiency (typical) | >86% | >88% | ||
| Working current | <2.6A 110VAC <1.6A 220VAC | |||
| Impulse current | 110VAC 20A, 220VAC 40A | |||
| Leakage current | 500ms,70ms,32ms :110VAC/500ms,70ms,36ms :220VAC | |||
| Protect | overload protection | 105%-150% Type:production mode:burp modde automatic recovery after the abnormal condition is lifted | ||
| Overvoltage protection | Output Voltage>135% will be restored automatically after it is removed | |||
| Short circuit protection | VO The output abnormal condition will be restored automatically after it is removed after the power is restarted | |||
| Environmental Science | Working temperature and humidity | -10ºC~+50ºC;20%~90RH | ||
| Storage temperature and humidity | -20ºC~+85ºC;10%~95RH | |||
| Safety regulations | Withstand voltage | I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P:0.5KVAC | ||
| leakage current | <1mA/240VAC | |||
| Insulation impedance | I/P-O/P, O/P-Shell, O/P-Shell :500VDC/100MΩ | |||
| Other | size | 65.5*125.2*100mm | ||
| Net weight / gross weight | 790/815g | |||
Q1:How many Voltage you can supply? A: 12v,24v,48v,50v,60v,110v(Depend on items).
Q2Can I have a sample order? A: Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable. At the same time, we have overseas warehouses so that you can get the products faster.
Q3Do you have any MOQ limited for the order? A: Low MOQ, 1pc for sample checking is available.
Q4How do you ship the goods and how long does it take to arrive? A: We usually ship by DHL, UPS, FedEx, or EMS. It usually takes 3-5 days to arrive. Airline and sea shipping is also optional.
Q5Do you offer a guarantee for the products? A: Yes, we offer a warranty on our products.
Q6: How to deal with the faulty? A: Firstly, our products are produced in a strict quality control system and the defective rate will be less. Secondly, during the guarantee period, we will send new products with new orders for small quantities.
For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to the real situation.
