100W  Switching Power Converter Transformer for LED Strip Light

Get reliable 100W Switching Power Converter Transformer for LED Strip Light from our factory. High-quality product to power your LED lights efficiently.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
AL-PS34
Voltage Regulating Mode
Width Modulation Type
Power Supplying System
Terminal Power Distribution Equipment
Energy Transmission
Two-way Transmission
Modulation System
PWM
Certification
CE, RoHS, ISO
Protection
Hipot, Short Circuit, Overvoltage, Ove
Quick Delievery
15-25 Days
Advantage
Long Lifetime, Surge Protecting
Efficiency
75%
Color
Custom
Experience
29 Years
Size
Custom
OEM
Welcome
Transport Package
Carton
Specification
5pcs/box
Trademark
AL
Origin
China
HS Code
8504401400
Production Capacity
5000PCS/15days

Product Description

Product Description

Customized Power Supply

1.electrical parameter


Technical Specification

Input

Voltage

AC 110V or 220V(with switch)



Frequency

50-60Hz

Output

Voltage

DC 12V



Current

12.5A  custom made



Power

150W  custom made



Typical Efficiency

73%



Adjustable Range of Voltage

DC 12V-12.5V



Max. Ripple & Noise

250mV

Protection

Over Load

105-115% of Rated Output Power



Short Circuit

Protection Type: Auto Recovery

Electric Strength

High-pot test

3KV AC

Environment

Working temperature and humidity

-10°C~+60°C,20~90%RH



Store temperature and humidity

20°C~+85°C,10~95%RH



MTBF

>200K hrs.@25°C(MIL-HDBK-217F)

Warranty

1 year

Feature

Dimension(L*W*H)

199*58*40mm



Weight

350g



Inner box size

205*102*46mm



Inner box weight

30g



PCS/CTN

40PCS/CTN



CTN size

500*220*433mm



GW/CTN

17kg

Safety & EMC

Safety Standards

EN55015/EN61000-3-2/EN61000-3-3


That's our normal specifications.  if you need more information welcome send us email to get the description of Specifications.


2.Advantages:

1) Superior raw material and Vendor Quality Audit

2) Has got UL,CE, EMC, BSMI,CCC, RoHS and Reach certificates.

3)100% Functional Test and electrical performance test, such as Hipot,short circuit,overvoltage,overload,overheat, burn-in test

4) 2 years quality warranty and defective rate is 0.5‰.

5)Provide Free samples for testing.

6)15-20 days fast delivery

7)Fast and high supply capacity, We not only supply high quality products,but also provide hot delivery service


100W Switching Power Converter Transformer for LED Strip Light
100W Switching Power Converter Transformer for LED Strip Light
Application

100W Switching Power Converter Transformer for LED Strip Light


Packaging & Shipping


100W Switching Power Converter Transformer for LED Strip Light



Our services

100W Switching Power Converter Transformer for LED Strip Light





Other products

100W Switching Power Converter Transformer for LED Strip Light


FAQ

1. Question: Lead time for samples?

    Reply: 5-6 working days.

2. Question: Lead time for mass production?

     Reply: 15 to 30 working days or depending on order quantity.

3. Question: What should provide to make custom  transformer ?

    Reply: Supply drawing is best, or tells us the size, inductance, resistance and etc.

4 . Question : What is payment term ?

    Reply : T/T , Western Union , PayPal or negotiation.
